Inverter
PX 6012 CIP
The PX6012 CIP is a professional-grade inverter UPS delivering 600W of clean, stable pure sine wave output—ideal for powering sensitive electronics. With built-in voltage stabilization, advanced multi-protection features, and a clear LCD interface, it ensures safe and efficient operation for critical devices.
At a glance
- Output: Pure sine wave
- Capacity: 600 W
- Battery: 12V
- Intelligent multi-stage charging
Pure sine wave output for all loads
DSP digital control technology
Adjustable charge current & voltage
Long backup time up to 10 hours
Flexible & intelligent power backup solution
PX 6012 CIP offers pure sine wave output with advanced DSP digital control and intelligent charger. Supports resistive, inductive, and motor loads, and can integrate optional MPPT for off-grid solar use.
Key Features Details
Battery temperature compensation and three-stage charging extend battery life and shorten recharge time.
Pure Sine Wave & DSP Control
Ensures stable, precise output suitable for various load types including motors and sensitive electronics.
Intelligent & Adjustable Charging
Charge current up to 60 A (default 20 A), adjustable via front panel for optimal battery management and efficiency.
Specification
| Specification | Details |
|---|---|
| Capacity | 600 W |
| Battery | 12 V |
| Output Waveform | Pure sine wave |
| Control | DSP digital control technology |
| Charge Current | Max. 60 A (adjustable, default 20 A) |
| Efficiency | Max. 95% (mains), Max. 80% (inverter) |
| Protections | Short circuit, overload, overcharge, undervoltage, overtemperature, low battery |
| Modes | No-load shutdown, ECO mode |
| Monitoring | LCD & buzzer interface |
| Dimensions (mm) | 280×258×120 (w/option) or 293×280×160 (w/option), wall mounted: 400×210×127 |
| Optional Modules | MPPT (solar), DC module |
